Descrição
Interface
PCI-Express 4.0 x4, NVMe 1.4
Form Factor
M.2 2280
Total Capacity
1000GB
Warranty
Limited 5-years or 700TBW
NAND
3D TLC NAND Flash
External DDR Cache
DDR4 1GB
Sequential Read speed
Up to 7000 MB/s
Sequential Write speed
Up to 5500 MB/s
Random Read IOPS
up to 350k
Random Write IOPS
up to 700k
Dimension
80.5 x 11.4 x 23.5 mm
Mean time between failure (MTBF)
1.6 million hours
Power Consumption (Active)
Average: R : 6.6W, W : 6.5W
Power Consumption (Idle)
<30mW
Temperature (Operating)
0°C to 70°C
Temperature (Storage)
-40°C to 85°C
Note
* Test system configuration: configuration may vary by models, we will choose the latest platform for verification.
* Performance may vary based on SSD's firmware version and system hardware & configuration. Sequential performance measurements based on CrystalDiskMark v.5.1.2 and I0meter 1.1.0.
* Speeds based on internal testing. Actual performance may vary.
* TBW (Terabyte Written):Terabytes Written" is the total amount of data that can be written into an SSD before it is likely to fail.
* 1GB = 1 billion bytes. Actual useable capacity may vary.
* 5 years or 700TBW, whichever comes first.
